| JMC-1000SFP+SX | 10/100/1000Base-TX TO 1000Base X Converter(LC Slot*1) +內含JS-S320SXD (MM LC 500m) |
| JMC-1000SFP+-LX | 10/100/1000Base-TX TO 1000Base X Converter(LC Slot*1) +內含JS-S430LXD (SM LC 10km) |
| JMC-1000SFP+BIDI (pair) | 10/100/1000Base-TX TO 1000Base X Converter(LC Slot*1) +內含SFP-1000BX20-35 ( 1310nm Simplex SM LC 20KM) |
| 10/100/1000Base-TX TO 1000Base X Converter(LC Slot*1) +內含SFP-1000BX20-53 ( 1550nm Simplex SM LC 20KM) |
Key Features
Interface
- TP Port - 10/100/1000Base-T RJ-45 x 1
- F/O Port - 100/1000Base-X x 1
Standards
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX/FX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3z 1000Base-X
- IEEE 802.3x Flow Control
- Auto-Negotiation in TX port
- MDI/MDIX Auto-Crossover supported
- Support Auto & Force mode configuration
- Support 9K Bytes jumbo frame
- Support Flow Control
- Operation: 0° ~ 50℃
- EMC/Safety FCC Class A, CE
