Ordering Information
|
Model |
Description |
Ethernet Port |
|
|
10/100/1000BaseT(X) |
SFP+ |
||
|
IVS-TN510-2X |
Industrial 10-port TSN Ethernet Switch |
8 |
2 |
|
IVS-TN508-2X |
Industrial 8-port TSN Ethernet Switch |
6 |
2 |
Features
- Provide 6/8 x 10/100/1000 Base-T ports, plus 2 x SFP+ slots
- 9K Jumbo Frames
- L2 wire-speed switching engine
- 32K MAC forwarding addresses
- Support TSN standard
- IEEE 1588 / 802.1AS-Rev qPTP (Generalized Precision Time Protocol)
- IEEE 802.1Qbv Time Aware Scheduling
- IEEE 802.1CB Seamless redundancy
- IEEE802.1Qbu Pre-emption / Cut-through
- Network redundant LACP; Spanning tree - STP, RSTP & MSTP; quick Ring fail-over protection (< 20 ms); G.8032 ERPS;
- Port-based /tag-based VLAN, IEEE 802.1ad/QinQ VLAN, Add/remove VLAN tags,
- Multicasting support IGMP v1/v2, proxy & snooping
- Multicast/Broadcast/Flooding Storm Control
- IEEE802.1x Access Control
- Per VLAN mirroring
- CLI/Web/SNMP management interfaces
- Dual power input & Reverse power protection
- DIN-Rail and Wall mounting option
