Model Name |
Description |
|
CVT-3002BTFC |
1000Base-TX to 1000Base-SX Converter(SC MM) 550M |
|
CVT-3002BTFC(SM-10)-PLUS |
1000Base-TX to 1000Base-LX Converter(SC SM 10km) |
|
CVT-3002BTFC(SM-30)-PLUS |
1000Base-TX to 1000Base-LX Converter(SC SM 30km) |
|
CVT-3002BTFC(SM-50)-PLUS |
1000Base-TX to 1000Base-LX Converter(SC SM 50km) |
|
CVT-3002BTFC(SM-80)-PLUS |
1000Base-TX to 1000Base-LX Converter(SC SM 80km) |
|
CVT-3002W2A-SM20 |
1000Base-TX to 1000Base-LX Converter(SC SM 20Km 1310nm) |
|
CVT-3002W2B-SM20 |
1000Base-TX to 1000Base-LX Converter(SC SM 20Km 1550nm) |
|
CVT-3002SFP-PLUS+SX |
10/100/1000Base-TX TO 1000Base X Converter(LC MM 500m) |
|
CVT-3002SFP-PLUS+LX |
10/100/1000Base-TX TO 1000Base X Converter(LC SM 10km) |
|
CVT-3002SFP-PLUS+LHX |
10/100/1000Base-TX TO 1000Base X Converter(LC SM 40km) |
|
CVT-3002SFP-PLUS+ZX |
10/100/1000Base-TX TO 1000Base X Converter(LC SM 80km) |
|
CVT-3002SFP-PLUS+BX20-35 |
10/100/1000Base-TX TO 1000Base X Converter(LC SM 20km 1310nm) |
|
CVT-3002SFP-PLUS+BX20-53 |
10/100/1000Base-TX TO 1000Base X Converter(LC SM 20km 1550nm) |
Key Features
Interface
- TP Port - 10/100/1000Base-T RJ-45 x 1
- F/O Port - 100/1000Base-X x 1
Standards
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-TX/FX
- IEEE 802.3ab 1000Base-T
- IEEE 802.3z 1000Base-X
- IEEE 802.3x Flow Control
- Auto-Negotiation in TX port
- MDI/MDIX Auto-Crossover supported
- Support Auto & Force mode configuration
- Support 9K Bytes jumbo frame
- Support Flow Control
- Operation: 0° ~ 50℃
- EMC/Safety FCC Class A, CE
